ProLiant DL560 Gen11

El ProLiant DL560 Gen11 es un servidor rack empresarial, en formato 2U, de la generación Gen11, de la línea ProLiant de HPE.

Procesador	4th Generation Intel® Xeon® Scalable Processors; 8 to 60 core, depending on processor.; 3.7 GHz maximum, depending on processor.
Memoria	16 TB with 256 GB DDR5 / (64 slots) / HPE DDR5 SmartMemory
Almacenamiento	8, 16, or 24 SFF SAS/SATA/SSD/NVMe, depending on configuration.
Fuente de poder	800W, 1000W, 1600W or 2200W Dual hot-plug redundant 1+1 redundant or 2+2 redundant or 3+1 redundant and 4+0 redundant, depending on model.
Slots de expansión	Up to 6 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs.
Puertos	1 Gb, 10 Gb, 10/25 Gb, 100 Gb, or 200 Gb, in PCIe adapter or OCP 3.0 form factor; for detailed descriptions reference the QuickSpecs.
Controlador RAID	HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller, HPE SR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller, HPE SR932i-p Gen11 x32 Lanes 8GB Wide Cache PCI SPDM Plug-in Storage Controller, HPE MR4
Controladores de almacenamiento	HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller, HPE SR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller, HPE SR932i-p Gen11 x32 Lanes 8GB Wide Cache PCI SPDM Plug-in Storage Controller, HPE MR4
Gestión	HPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE OneView Advanced (optional, requires licenses), and HPE Compute Ops Management.
Seguridad	HPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit.
Garantía	3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://support.hpe.com/hpesc/p
Factor de forma	2U rack server (4-socket)

Para especificaciones técnicas completas, consulte el datasheet oficial del fabricante.

MarcaHPE

Procesador4th Generation Intel® Xeon® Scalable Processors; 8 to 60 core, depending on processor.; 3.7 GHz maximum, depending on processor.

Cantidad de RAM256GB

Tipo de DiscoUniversal (SAS/SATA/NVMe)

Línea / Serie de ServidorProLiant

Tipo de ServidorServidor Rack

Factor de Forma2U

GeneraciónGen11

Sockets de CPUNo aplica

Soporte GPU / AceleradorNo

ModeloProLiant DL560 Gen11

Memoria16 TB with 256 GB DDR5 / (64 slots) / HPE DDR5 SmartMemory

Almacenamiento8, 16, or 24 SFF SAS/SATA/SSD/NVMe, depending on configuration.

RAIDHPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller, HPE SR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller, HPE SR932i-p Gen11 x32 Lanes 8GB Wide…

Controlador de AlmacenamientoHPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller, HPE SR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller, HPE SR932i-p Gen11 x32 Lanes 8GB Wide…

Fuente de Poder800W, 1000W, 1600W or 2200W Dual hot-plug redundant 1+1 redundant or 2+2 redundant or 3+1 redundant and 4+0 redundant, depending on model.

Puertos1 Gb, 10 Gb, 10/25 Gb, 100 Gb, or 200 Gb, in PCIe adapter or OCP 3.0 form factor; for detailed descriptions reference the QuickSpecs.

Slots PCIeUp to 6 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs.

Chasis2U rack server (4-socket)

SeguridadHPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit.

Gestión RemotaHPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE OneView Advanced (optional, requires licenses), and HPE Compute Op…

Soporte y Garantía3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical suppo…

URL DatasheetDescargar Datasheet

URL ProductoVer enlace
